CANNY Product Catalog

Сommercially available devices

Programmable Logic CAN-controller CANNY•7

Programmable Logic CAN-controller CANNY•7

CANNY•7 — A unique tool that allows you to create a completely finished, ready for integration with the on-board system of a vehicle or another controllable object, original electronic device in minutes.

More...
CANNY•7 Demo Kit

CANNY•7 Demo Kit

CANNY 7 Demo Kit It is intended to increase the visibility and simplify the debugging process of the functional diagrams for CANNY•7 controller.

More...
Programmable Logic CAN controller CANNY•5.3 MD1A

Programmable Logic CAN controller CANNY•5.3 MD1A

CANNY•5.3 MD1A — small-sized, cost-effective CAN/LIN controller with two half-bridge power outputs and three discrete IO channels and protected ADC.

More...
Programmable Logic 2xCAN controller CANNY•7.2 Duo

Programmable Logic 2xCAN controller CANNY•7.2 Duo

CANNY•7.2 Duo – The brand new commercially available automotive programmable logic controller with a wide range of supply voltages, dual CAN, nine IO, up to four LIN and an internal ADC.

More...
Programmable Logic CAN controller CANNY•5.3 Pico

Programmable Logic CAN controller CANNY•5.3 Pico

CANNY•5.3 Pico — small-sized, cost-effective CAN/LIN controller with three discrete IO channels and protected ADC.

More...
Graphical Integrated Development Environment CannyLab

Graphical Integrated Development Environment CannyLab

CannyLab — original Integrated Development Environment for CANNY controllers includes Visual Programming Language turn implementing your ideas into a enthralling process. The animated simulator and one-click PC-to-controller uploading will radically speed up the convertation of your ideas into a real, touchable and responsive device.

More...

Comparison Table

Total count of low power input / output channels

11

9

4

3

Low power high side output channels

11

9

3

3

Low power low side output channels

11

9

3

3

Total count of inputs

11

9

3

3

Maximum current per Low Power channel / total

100mA / 1000mA

100mA / 900mA

100mA / 300mA

100mA / 300mA

Maximum voltage on the any IO channel

18V

32V

18V

18V

Smart IO overcurrent protection

Yes

Yes

Yes

Yes

Number of CAN 2.0B interfaces

1

2

1

1

Number of UART interfaces

up to 2

up to 4

up to 2

up to 2

Number of USB Virtual COM Port interfaces

--

1

--

Number of LIN interfaces

up to 2

up to 4

up to 2

up to 2

Number of I2C interfaces

up to 5

--

--

Number of Dallas 1-Wire interfaces

up to 11

up to 9

1

Number of IR remote

up to 11

up to 9

--

Number of ADC

--

up to 1

1

2

Number of PWM/HF PWM

6/2

9/6

3/3

3/3

Max. resolution PWM/HF PWM

100μs/1,33μs

1ms/1,07μs

1ms/1μs

1ms/1μsс

Number of asynchronous counter inputs

11

9

3

3

Performance index

234

591

173

490

Firmware update interface

USB

USB

USB

USB

Visual programming

Yes

Yes

Yes

Yes

CANNY CAN/LIN monitor mode support

Yes

Yes

Yes

Yes

Supply voltage, VDC

9...18V

7...30V

7...18V

7...18V

Current consumption in operating mode, max

55mA

70mA

22mA

40mA

Current consumption in sleep mode, min

5mA

1mA

1mA

1mA

Operating temperature range

-40C...+85C

-40C...+85C

-40C...+85C

-40...+85

Ingress Protection Rating

IP50

IP50

caseless

IP20

Dimensions: LxBxH, мм

76x29x18

76x29x13

40x15x4

70x29x13
